SELECT TL1 toilet lifter, for wall outlet
Product number: R8022112
EAN: 5708590345338
Manually height adjustable 300 mm (425-725 mm) with crank handle.
Description
- Product description
- Different heights to suit different users/transfer techniques
- Manual or powered adjustment to suit different requirements - frequent/periodic adjustment
- Allows a range of WC's to be fitted for a bespoke solution
- The aim is to make it as easy as possible for users to get on and off the toilet during daily use. The aim is also to make the carer’s work easier, and make the process comfortable and dignified for the user.
- SELECT TL1 toilet lifter, 300 mm manually height adjustable, with crank handle.
Incl. cistern with dual flushing system preset at 3/6 litres.
Toilet pan and toilet seat to be ordered separately.
For wall-outlet.
Materials: Anodised aluminium and polystyrene (PS).
Excl. mounting kit.
- Intended use
- Toilet lifters ensure optimum ergonomics at a toilet, for both seated and standing users with disabilities.
Expected service life is 10 years, provided that maintenance is carried out as described in the user manual. - Features
- The toilet can be raised and lowered using the crank handle. The crank handle can be positioned on either side of the lifter – without the need for tools.
It is possible to adjust the height of the toilet lifter using an electric drill as an alternative to the crank handle.
The toilet can be adjusted 300 mm, from 425 mm to 725 mm in height , so the height can always be perfectly matched to mobility aids such as a wheelchair. - Ergonomy
- Toilet lifters are available in three different colours which all harmonise with modern bathrooms, resulting in a comfortable and inviting toilet environment. A minimum of grooves, slots and holes makes cleaning fast and effective, and also results in an attractive and exclusive design.
- ProductAttributes.ProductIntendedUse
- TOILET LIFTERS
- Product capacity
- Maximum user weight: 200 kg.
Maximum load: 235 kg. (user weight + accessories).
When the toilet lifter is loaded with 235 kg, each wall fastener is loaded with 65 kg.
The toilet lifter has been tested statically with 600 kg, which is a requirement according to the applied assistive products standards. Please note that most toilet pans compatible with this lifter have been tested up to 400 kg. - Warranty
- Pressalit makes a commitment to remedy material and manufacturing defects for a period of five years from the invoicing date.
Specifications
- Product codes
EAN
5708590345338VVS
617990112ETIM
EC010062NRF
6191044HMI
105968GMDN
63053FDA
IKX/D319729UNSPSC
42211615
- Product group
- Toilet lifters
- Dimensioned drawing, mm
- Adjustability
- Height adjustable
- Adjustment height, mm
- 300
- Maximum user weight (MUM), kg
- 200
- Safe working load (SWL), kg
- 235
- Declaration of conformity
- This product is produced in compliance with all relevant requirements of:
- Regulation (EU) 2017/745 on medical devices (Risk class I, rule 1)
- Council Directive 2006/42/EC on machinery
For the UK:
- Medical Device Regulation (MDR) 2002 on medical devices
- Supply of Machinery (Safety) Regulations 2008 - Colour
- Anthracite grey
- Designer
- Rasmus Thygesen
- Design year
- 2013
- Materials
- Anodized aluminium.
The front plates are made of polystyrene (PS).
Top plate in compact laminate.
Flammability-tested (ISO 8191-1 and ISO 8191-2). Test report available. - Cleaning
SELECT TL1, TL2 toilet lifter
The product is to be cleaned with hot water or a mild soapy cleaning agent.
Do not use chlorine based, corrosive or abrasive cleaners as it may result in the surface being damaged.
The following cleaning agents have been tested by Pressalit and may be used, as long as they are diluted according to the instructions on the container.
DISINFECTANTS:
Clinimax Difficil-S
Erisan OXY+
Sprit (husholdningssprit)
Suma Bac D10
Virkon
Rodalon Desinfektionsspray
Lysoformin Spezial
CaviCide
Sufanios Premium
Tvättsprit 70%
NON-DISINFECTANTS:
Suma Star free D1
Taski 100
Taski 200
Milizid Citro
The product must be wiped down with a soft rag wrung out in clear water immediately after cleaning, as some materials may otherwise be discolored and stained, and the surface coating may deteriorate.
DECALCIFICATION OF ALUMINUM PARTS:
Pressalit recommends that chalky deposits be removed from wall tracks and other aluminum parts using a solution of three parts 30% acetic acid to seven parts tap water. When the aluminum parts have been washed down with this solution, the parts must be wiped over with a damp cloth wrung out in clear water.- Sales unit
- pcs
- Net weight, kg
- 52.3
- Gross weight, kg
- 55.3
- Weight per crate, kg
- 55.3
- Crates per pallet
- 1
- Qty per crate
- 1
- Qty per pallet
- 1
Mounting
- Mounting
- Excl. mounting kit. See Technical datasheet (pdf) for information on mounting kits suitable for various wall types.
