PLUS support arm with integrated counter-balance, 700 mm
Product number: R381470000
EAN: 5708590368696
Previous versions: R3516
Projection: 730 mm.
Sideways adjustable.
Removable and foldable
Sideways adjustable.
Removable and foldable
Description
- Product description
- Easy lift on/off horizontal track
- Easy to slide e.g from toilet to shower
- All PLUS support arms come with an integrated counter-balance, which ensures a controlled movement between horizontal and vertical positions.
Suitable for use with toilet pans projecting 540/550 mm. - PLUS support arm. Projection 730 mm, ergonomically shaped to provide a clear sense of where the support arm ends. Sideways adjustable. Detachable and foldable.
Materials: The arms are constructed of 10-micrometre anodized aluminium, with a non-slip gripping surface made of soft SEBS incorporating a glass-reinforced nylon core
For fitting to horizontal PLUS wall track (not included). - PLUS SUPPORT ARMS – Red Dot Product Design Award winner
Ergonomic design and integrated counter-balance function makes the support arms a user-friendly and safe choice.
The Red Dot Product Design Award is an international design award that honors product design, communication design and design concepts.
The distinction “Red Dot” has become established internationally as one of the most sought-after seals of quality for good design.
- Intended use
- The support arm is used as a suport for a user, when he or she sits down or gets up from a toilet.
Expected service life is 10 years, provided that maintenance is carried out as described in the user manual. - Features
- Folds against the wall.
The underside is shaped for the mounting of various accessories. - Ergonomy
- The oval shape gives an easy and comfortable surface to lean and push against.
The end of the support arm is enlarged so that it is easier to pull forward from a sitting position and also provides a clear sense of where the support arm ends.
Soft and slip-resistant material that has a warm feel. - ProductAttributes.ProductIntendedUse
- SUPPORT ARMS
- Product capacity
- Maximum load: 150 kg.
When the support arm is loaded with 150 kg, each wall fastener in the horizontal wall track is loaded with 16 kg.
PLUS support arms have been tested statically with 700 kg (close to the wall), 425 kg (in the middle) and 225 kg (the outermost point). - Warranty
- Pressalit makes a commitment to remedy material and manufacturing defects for a period of five years from the invoicing date.
Specifications
- Product codes
EAN
5708590368696VVS
615881400ETIM
EC010078NRF
6191144RSK
8487448HMI
123653GMDN
35585FDA
ILS/D135866UNSPSC
42211612
- Previous version
- R3516
- Product group
- Support arms and arm supports
- Dimensioned drawing, mm
- Adjustability
- Sideways adjustable
- Adjustment height, mm
- 240
- Maximum user weight (MUM), kg
- 150
- Declaration of conformity
- This product is produced in compliance with all relevant requirements of:
- Regulation (EU) 2017/745 on medical devices (Risk class I, rule 1) - Colour
- White
- Designer
- Rasmus Thygesen
- Design year
- 2011
- Materials
- The arms are primarily constructed in 10-micrometre anodized aluminium, with a non-slip gripping surface at the end made of soft SEBS and incorporating a glass-reinforced nylon core.
The hinge arm is also made of soft SEBS.
Internal components and fasteners are primarily made of stainless steel.
The hinge barrel is capped with ABS polymer. - Cleaning
PLUS support arms
The product is to be cleaned with hot water or a mild soapy cleaning agent.
Do not use chlorine based, corrosive or abrasive cleaners as it may result in the surface being damaged.
The following cleaning agents have been tested by Pressalit and may be used, as long as they are diluted according to the instructions on the container.
DISINFECTANTS:
Clinimax Difficil-S
Erisan OXY+
Sprit (husholdningssprit)
Suma Bac D10
Virkon
Rodalon Desinfektionsspray
Lysoformin Spezial
CaviCide
Sufanios Premium
Tvättsprit 70%
Oxyplus-acid 2% (Diversey)
WipeClean UniversalCleaning
Chrolorine Disinfection Wipes
NON-DISINFECTANTS:
Suma Star free D1
Taski 100
Taski 200
Milizid Citro
The product must be wiped down with a soft rag wrung out in clear water immediately after cleaning, as some materials may otherwise be discolored and stained, and the surface coating may deteriorate.
DECALCIFICATION OF ALUMINUM PARTS:
Pressalit recommends that chalky deposits be removed from wall tracks and other aluminum parts using a solution of three parts 30% acetic acid to seven parts tap water. When the aluminum parts have been washed down with this solution, the parts must be wiped over with a damp cloth wrung out in clear water.- Sales unit
- pcs
- Net weight, kg
- 2.8
- Gross weight, kg
- 4.3
- Weight per crate, kg
- 4.3
- Crates per pallet
- 24
- Qty per crate
- 1
- Qty per pallet
- 24
- Carton size
- 1045x200x235 mm
Mounting
- Mounting
- For fitting to horizontal PLUS wall track (not included).
